ORING Ies-3080

Price 16000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

ORING Ies-3080 Specification

Product Type
Industrial Managed Ethernet Switch

Number of Channels
8

Storage Temperature
-40C to 85C

Network Connection Methods
10/100 Mbps Ethernet

Power
Redundant power inputs, 12~48VDC

Dimension (L*W*H)
152mm x 106mm x 56mm

Weight
~700g

Range
100 meters per segment

Usage
Industrial Networking

Power Supply
Dual DC inputs

Material
Metal Housing

Led Indicator
Power, Fault, Link/Activity per port

Size
152mm x 106mm x 56mm

No. of Ports/Pins
8 (10/100Base-T(X) RJ-45 ports)

Height
56mm

Color
Black

ORING Ies-3080 Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

About ORING Ies-3080

Fastest Redundant Ethernet Ring: O-Ring (recovery time < 10ms over 250 units of connection) O-Chain allow multiple redundant networks rings Support standard IEC 62439-2 MRP. RMON for traffic monitoring Support PTP Client (Precision Time Protocol) clock synchronization Provided HTTPS/SSH protocol to enhance network security DIN-Rail and wall mounting enabled

Industrial-Grade Performance

The ORING IES-3080 ensures reliable network communications in challenging industrial settings. Engineered for harsh conditions, its wide operating temperature range and IP30-rated metal housing provide dependable performance even in extreme environments. The device is suitable for applications such as factory automation, railway systems, and power utilities.

Simplified Installation & Maintenance

This switch supports easy DIN-rail mounting, enabling quick integration into control cabinets or industrial enclosures. LED indicators for power, fault, and link/activity on each port facilitate on-site monitoring and maintenance, minimizing downtime and enhancing operational safety for both installers and end-users.

Seamless Network Expansion

With eight 10/100 Mbps RJ-45 ports and a MAC table supporting up to 2K addresses, the ORING IES-3080 smoothly scales to accommodate growing industrial networks. Its 100-meter segment range meets common Ethernet standards, making network planning straightforward in extensive site layouts.

FAQ's of ORING Ies-3080:

Q: How is the ORING IES-3080 installed in an industrial setup?

A: The ORING IES-3080 is designed for DIN-rail mounting, allowing for quick and secure installation in standard industrial enclosures or panels. This easy mounting process helps streamline integration into new or existing network cabinets.

Q: What benefits does the redundant power input provide?

A: Redundant power inputs (dual 12-48VDC) ensure continuous operation by allowing one input to take over if the other fails, minimizing the risk of network interruptions and enhancing reliability in mission-critical applications.

Q: When should you use the IES-3080 in your network?

A: Deploy the IES-3080 when robust network connectivity is required in demanding environments-with extreme temperatures, vibrations, or dust-such as in manufacturing plants, railways, or utility substations.

Q: Where can the ORING IES-3080 be positioned within a network system?

A: The IES-3080 is best positioned at distribution or edge points within an industrial network, where multiple devices or subsystems need to communicate reliably over Ethernet, within the allowable 100-meter cable range per segment.

Q: What is the primary advantage of the switch's metal housing and IP30 rating?

A: Its metal housing and IP30 ingress protection provide resistance to physical impact and protect internal components against dust, making it suitable for harsh, industrial environments.

Q: How does the MAC table size affect network performance?

A: A 2K MAC address table enables the switch to handle up to 2,000 unique devices or endpoints, ensuring efficient tracking and switching of network traffic even as the connected network grows.
