MACHFLEX LIYCY (TP) (4P0.75YCY F2V500M)

Price 225.0 INR/ Meter

Get a Price/Quote

MACHFLEX LIYCY (TP) (4P0.75YCY F2V500M) Specification

Core Material
Tinned Copper

Insulation
PVC

Conductor Type
Flexible

Weight
Approx. 18 kg per 500m

Rated Temperature
+70 C

Operating Temperature
-30C to +70C

Cable Type
Screened Twisted Pair

Core Number
4 pairs

Features
Flexible, Shielded, Flame Retardant, Low Capacitance, Screened Pairs

Usage & Applications
Instrumentation, Data, Measurement, Control Systems

Impedance
Approx. 120 Ohm

Conductor Shape
Round

Install Type
Fixed Installation

Dielectiric Strength
2 KV

Diameter
Approx. 8.2 mm

Number of Conductor
8 (4 pairs)

Tensile Strength
High (As per IEC standards)

Product Type
Screened Data Transmission Cable

Length
500 meters

Voltage
300 V

Insulation Material
PVC

Application
Control, Signal, Data Transmission, Electronics

Conductor Material
Stranded Tinned Copper

Jacket Material
PVC

Storage Temperature
-5C to +50C

Connector Color
Silver

Shield Material
Tinned Copper Braiding

Jacket Color
Grey

Dimension (L*W*H)
Standard per IEC norms

Material
Copper / PVC

Color
Grey

Size
0.75 sqmm

Fire Propagation Test
IEC 60332-3-24

Norms/Approvals
VDE 0812/EN 50525-2-11

Core Insulation Thickness
Approx. 0.6 mm

Pair Construction
Pair-wise Twisted Conductors

Flame Retardant Standard
IEC 60332-1

Test Voltage
1500 V AC

Pair Identification
Coded according to DIN 47100

Screen Coverage
Tinned Copper Braid Coverage 85%

Halogen Content
Halogen Free

Capacitance (core-core)
Approx. 120 nF/km

Outer Sheath Thickness
Approx. 0.9 mm

Minimum Bending Radius
7.5 x Outer Diameter

MACHFLEX LIYCY (TP) (4P0.75YCY F2V500M) Trade Information

Minimum Order Quantity
100 Meter

Main Domestic Market
All India

About MACHFLEX LIYCY (TP) (4P0.75YCY F2V500M)

Belden 4P0.75ycy multi core flexible cable, liycy twisted pair pvc control AND signal cables, tinned copper braid shield (tcb) excellent noise immunity, liycy (tp) control cable pvc cables

Exceptional Electrical Performance

Designed for precise data, signal, and control transmissions, MACHFLEX LIYCY (TP) features low capacitance and approx. 120 Ohm impedance for optimal signal clarity. The pair-wise twisted, screened construction alongside robust dielectric strength up to 2 KV minimizes electromagnetic interference, supporting reliable operations in demanding environments.

Advanced Safety and Compliance

Compliant with VDE 0812, EN 50525-2-11, and multiple IEC flame retardant standards (IEC 60332-1 and IEC 60332-3-24), this cable offers superior fire resistance and halogen-free safety. Its construction ensures safe integration in industrial and commercial settings, meeting stringent international norms for fire propagation and toxic-free emissions.

Optimized Flexibility and Durability

MACHFLEX LIYCY (TP) uses stranded tinned copper conductors and a flexible PVC outer sheath for high tensile strength and bending radius (7.5x OD). Its robust design (diameter approx. 8.2 mm, weight approx. 18 kg/500m) ensures long-term reliability for fixed installations without compromising flexibility and ease of installation.

FAQs of MACHFLEX LIYCY (TP) (4P0.75YCY F2V500M):

Q: How does the MACHFLEX LIYCY (TP) cable maintain signal integrity during data transmission?

A: The cable uses pair-wise twisted conductors with tinned copper braiding that provides over 85% coverage. This combination minimizes electromagnetic interference and crosstalk, ensuring clear and stable signal transmission, even in environments with significant external electrical noise.

Q: What applications is this cable best suited for and why?

A: MACHFLEX LIYCY (TP) is ideal for control, signal, data transmission, instrumentation, and measurement systems in industrial, commercial, and electronics environments. Its screened and flame-retardant construction makes it highly suitable for critical systems requiring reliable and interference-free connectivity.

Q: When should the cable be used in installations?

A: Use this cable in fixed installations where high flexibility, safety, and shielded data transmission are required, such as in control panels, electronic instrumentation, and automation setups. It is particularly effective when compliance with international fire and halogen-free standards is necessary.

Q: Where should MACHFLEX LIYCY (TP) not be installed?

A: Avoid using this cable in situations where exposure to temperatures outside -30C to +70C or applications demanding mobile (repeatedly flexible) cable arrangements are common, as it is specifically designed for fixed installations and could be damaged in highly dynamic environments.

Q: What is the benefit of the cables halogen-free and flame-retardant features?

A: The halogen-free and flame-retardant design ensures minimal toxic emission and prevents fire spread in case of combustion, meeting IEC 60332 standards. This enhances safety for personnel and equipment in enclosed or sensitive areas.

Q: How should the minimum bending radius be observed during installation?

A: Ensure that the cable is not bent tighter than 7.5 times its outer diametermeaning approximately 61.5 mmfor safe installation and to maintain cable integrity and longevity, according to VDE and IEC regulations.

Q: What process is used to identify the pairs within this cable?

A: Pair identification follows DIN 47100 coding, with each core color-coded for easy and accurate identification during installation, simplifying troubleshooting and reducing wiring errors.
