BELDEN 4694F

Price 265 INR/ Meter

Get a Price/Quote

BELDEN 4694F Specification

Diameter
7.0 mm

Install Type
Flexible, Reel, Fixed installation

Rated Temperature
-20C to +60C

Dielectiric Strength
3500V RMS (Min)

Insulation
Gas-injected Foam Polyethylene

Number of Conductor
1

Conductor Type
Coaxial

Usage & Applications
High-speed 4K/8K video transmission, professional broadcasting facilities

Operating Temperature
-20C to +60C

Weight
46 kg/km

Core Material
Bare Copper

Features
High-definition video performance, Flexible, Low signal loss, 12G-SDI, Flame retardant, RoHS compliant

Conductor Shape
Solid

Core Number
Single core

Impedance
75 Ohms

Cable Type
Coaxial, 12G-SDI, Single-core

Product Type
Flexible Coaxial Cable

Length
Available in custom lengths, up to 305 meters (1000 ft) per reel

Voltage
30V RMS

Insulation Material
Gas-injected Foam Polyethylene (FPE)

Application
Digital video transmission, HDTV, Broadcast, Studio, Outside broadcast trucks

Conductor Material
Bare Copper

Jacket Material
PVC, Non-black jackets are available

Storage Temperature
-40C to +70C

Shield Material
Tinned Copper Braid with Aluminum-Polyester Tape

Jacket Color
Black (standard), custom colors on request

Dimension (L*W*H)
Diameter: 7.0 mm (0.276 in)

Material
Copper, FPE, PVC

Color
Black

Size
7.0 mm OD

Shield Coverage
95% Braid Coverage plus 100% Aluminum-Polyester Foil

Dielectric Diameter
4.57 mm (0.180 in)

Attenuation at 3 GHz
14.2 dB/100 meters

Outer Jacket Thickness
1.02 mm (0.040 in)

Flame Test
UL 1666

UL Rating
CMR

Attenuation at 1 GHz
8.0 dB/100 meters

Inner Conductor Diameter
1.62 mm (0.064 in)

Minimum Bend Radius
70 mm (2.76 in)

BELDEN 4694F Trade Information

Minimum Order Quantity
305 Meter

Main Domestic Market
All India

About BELDEN 4694F

12 GHz Coax, 4K UHD Precision Flexible Video Cable, RG-6/U Type, 75 Ohm, 18 AWG solid .040" silver plated copper conductor, gas-injected foam HDPE insulation, dual tinned copper braid shield (95% coverage each), CM, PVC jacket.

Engineered for Superior High-Definition Video

BELDEN 4694F supports high-speed 12G-SDI transmission, ensuring pristine, real-time video for professional broadcasting and performance-intensive environments. Its solid copper conductor and gas-injected FPE insulation minimize signal loss, enabling reliable 4K and 8K video delivery, even across long distances.

Robust Construction for Demanding Applications

Built with a 95% tinned copper braid and 100% aluminum-polyester foil shield, the cable offers outstanding protection from external interference. The PVC jacket is flame retardant, passing UL 1666, and the cable is CMR rated-qualified for use in riser and commercial spaces.

Flexible for Easy Installation

With a minimum bend radius of 70 mm, BELDEN 4694F is designed for both flexible and fixed installations, whether in broadcast studios, outside broadcast trucks, or complex routing in commercial sites. Standard black jacket and custom color options enhance deployment flexibility.

FAQ's of BELDEN 4694F:

Q: How does the BELDEN 4694F ensure low signal loss in high-definition video applications?

A: BELDEN 4694F achieves low signal loss through its solid bare copper conductor and gas-injected foam polyethylene insulation, resulting in attenuation rates as low as 8.0 dB/100 meters at 1 GHz and 14.2 dB/100 meters at 3 GHz.

Q: What installation environments are suitable for the BELDEN 4694F cable?

A: The BELDEN 4694F is CMR-rated and UL 1666 flame-tested, making it suitable for commercial riser spaces, studios, outside broadcast trucks, and other professional broadcast facilities requiring high fire safety and performance.

Q: When is custom jacket color or length available for BELDEN 4694F?

A: Custom jacket colors and cable lengths are available upon request. The standard color is black, but clients can specify custom colors. Cable is supplied in custom lengths up to 305 meters (1000 ft) per reel.

Q: Where can BELDEN 4694F be used to its best advantage?

A: This cable excels in digital video transmission settings such as 12G-SDI professional broadcasting, HDTV facilities, studios, and mobile production vehicles requiring reliable 4K or 8K video transfer.

Q: What benefits does the dual shielding design offer?

A: With 95% tinned copper braid coverage and 100% aluminum-polyester foil, BELDEN 4694F ensures superior protection against electromagnetic and radio frequency interference, maintaining signal clarity in challenging environments.

Q: How flexible is BELDEN 4694F for routing during installation?

A: Designed with a flexible construction and a minimum bend radius of 70 mm, the cable is ideal for applications where tight bends or complex routes are necessary.
