BELDEN 1510C

Name: BELDEN 1510C
Brand: P&S INNOVATION
Price: 305.0 INR
Availability: InStock

Price 305.0 INR/ Meter

Get a Price/Quote

BELDEN 1510C Specification

Insulation
Polyethylene

Rated Temperature
-20°C to +60°C

Features
Low capacitance, Flexible, Tinned copper conductors, Shielded, High signal integrity

Weight
Approx. 45 kg/km

Cable Type
Multi-conductor, Shielded

Impedance
Non-impedance rated (low capacitance)

Diameter
Approx. 4.95 mm

Operating Temperature
-20°C to +60°C

Conductor Shape
Round

Core Material
Tinned Copper

Core Number
3

Number of Conductor
3

Dielectiric Strength
1500 V RMS

Install Type
Indoor, Fixed installation

Conductor Type
Stranded

Usage & Applications
Audio, Data, Instrumentation, Control

Product Type
Shielded Audio/Instrumentation Cable

Length
305 meters (1000 feet)

Voltage
300 V

Insulation Material
Polyethylene (PE)

Application
Audio, Data transmission, Security systems, Instrumentation

Conductor Material
Tinned Copper

Jacket Material
PVC (Polyvinyl Chloride)

Storage Temperature
-30°C to +75°C

Connector Color
N/A (Cable only)

Shield Material
Aluminum polyester foil with tinned copper drain wire

Jacket Color
Gray

Dimension (L*W*H)
305m roll; Cable OD approx. 4.95 mm

Color
Gray

Material
Tinned Copper/PVC/PE

Size
20 AWG

RoHS Compliance
Yes

Drain Wire
Yes, 20 AWG stranded tinned copper

Reference Standard
UL AWM Style 2464, NEC Type CMG

Capacitance (Cond. to Cond./Ft)
23 pF/ft @ 1 kHz

Flame Test
UL 1685, IEC 60332-1

Rip Cord
Present

Capacitance (Cond. to Other Cond., Shield/Ft)
41 pF/ft @ 1 kHz

Voltage Rating
300 V RMS

BELDEN 1510C Trade Information

Minimum Order Quantity
100 Meter

Main Domestic Market
All India

BELDEN 1510C About

Audio Snake Cable, CM-Rated, 4-24 AWG tinned copper pairs, polyolefin insulation, individually shielded with Beldfoil bonded to numbered/color-coded PVC jackets so both strip simulteaneously, overall Beldfoil shield, drain, flexible PVC jacke

Additional Information:

Item Code: 1510C

Superior Signal Integrity and Performance

BELDEN 1510C cable uses shielded, low-capacitance construction to deliver excellent signal clarity in demanding applications. Its tinned copper conductors and foil shielding reduce interference, making it suitable for precise data and audio transfer over long distances. Enhanced flexibility and robust materials ensure reliable performance in permanent installations.

Safety and Compliance

This cable meets stringent safety standards, including UL AWM Style 2464 and NEC Type CMG, with flame testing per UL 1685 and IEC 60332-1. The RoHS compliance ensures the product is environmentally friendly. Its dielectrically strong insulation and jacket materials provide added protection for sensitive systems.

Versatile Installation and Usage

BELDEN 1510C is designed for a broad range of applications, including audio systems, data networks, control circuits, and security devices. Its durable construction and flexible design make installation straightforward in indoor, fixed environments, whether in commercial, industrial, or residential settings.

FAQ's of BELDEN 1510C:

Q: How is BELDEN 1510C cable installed for optimal performance?

A: For best results, install BELDEN 1510C in indoor, fixed locations where minimal movement occurs. Ensure the cable is routed away from electrical noise sources and sharp bends, using standard cable management practices. The flexible PVC jacket and built-in rip cord simplify cutting and stripping during installation.

Q: What applications are suitable for BELDEN 1510C cable?

A: BELDEN 1510C is designed for audio transmission, data networking, security systems, instrumentation, and control circuits. Its low capacitance and shielding make it ideal for installations requiring high signal integrity and noise reduction.

Q: When should shielded, low-capacitance cables like BELDEN 1510C be used?

A: Shielded, low-capacitance cables are recommended when you need reliable signal transfer over longer runs, or in environments with significant electrical interference. Use BELDEN 1510C whenever consistent data, audio, or control signal quality is critical.

Q: Where can BELDEN 1510C be deployed in India?

A: BELDEN 1510C can be installed in commercial buildings, factories, studios, institutions, and residences nationwide. It's suitable for use by exporters, importers, manufacturers, and suppliers across India, particularly for indoor fixed setups.

Q: What is the process for maintaining BELDEN 1510C cable after installation?

A: Maintaining BELDEN 1510C involves regular inspections for physical damage, ensuring connections are secure, and keeping the cable free of moisture and excessive heat. The cable's durable jacket and low maintenance design help ensure long-term reliability.

Q: How does the cable's shielding benefit signal transmission?

A: The aluminum polyester foil shield with tinned copper drain wire protects signals from electromagnetic and radio frequency interference. This ensures clearer audio and data transmission, particularly in environments with competing electronic equipment.

Q: What are the advantages of using BELDEN 1510C in professional installations?

A: BELDEN 1510C offers enhanced signal fidelity, flexible handling, robust safety compliance, and broad applicability. Its low-capacitance design prevents signal loss, making it a trusted choice for technicians seeking reliability and performance in audio, data, and instrumentation projects.
