LAN Cables STP

Name: LAN Cables STP
Brand: P&S INNOVATION
Price: 19825.0 INR
Availability: InStock

Price 19825.0 INR/ Box

Get a Price/Quote

MOQ : 1 Box

LAN Cables STP Specification

Dielectiric Strength
1.5 kV for 1 minute

Conductor Shape
Round

Locking Type
Standard RJ45 modular connectors

Number of Conductor
8 (4 pairs)

Install Type
Indoor

Impedance
100 15 Ohm

Rated Temperature
-20C to +75C

Operating Temperature
-20C to +75C

Usage & Applications
Networking, data centers, office wiring, patch cables, rack installations

Weight
Approx. 35 kg per box of 305 m

Core Material
Copper

Features
Shielded twisted pairs to minimize electromagnetic interference, stable data transmission, reduced crosstalk, robust construction suitable for networking applications

Diameter
6.2 mm (nominal)

Cable Type
STP

Conductor Type
Solid or Stranded

Core Number
4 twisted pairs (8 cores)

Insulation
High-density polyethylene

Tensile Strength
Min. 10 N/mm2

Product Type
Shielded Twisted Pair (STP) LAN Cable

Length
Upto 305 meters (custom lengths available)

Voltage
300V max

Insulation Material
Other

Application
Industrial

Conductor Material
Pure copper

Jacket Material
Polyvinyl Chloride (PVC)

Storage Temperature
-40C to +70C

Connector Color
Silver/metallic (depends on connector type)

Shield Material
Aluminum foil with braided copper

Jacket Color
Other

Dimension (L*W*H)
As per cable length and type

Color
Grey

Material
Copper, PVC, aluminum foil

Size
23AWG (Standard)

Bandwidth
Up to 250 MHz (Cat 6)

Resistance
Max. 9.38 /100 m at 20C

UV Resistant
No (for indoor use)

Pair Count
4 pairs

Packing
305m pull box, custom lengths available

Compliance Standard
ANSI/TIA-568-C.2

Pair Shielding
Individual pair shielding

Flame Retardant
Yes, complies with IEC 60332-1

Contact Plating
50 micron gold-plated contacts

RoHS Compliant
Yes

Cross Filler
Yes, to minimize crosstalk

Outer Shielding
Overall braid and foil

Minimum Bend Radius
4 x cable diameter

Support
Supports PoE and PoE+

Inner sheath material
HDPE

LAN Cables STP Trade Information

Minimum Order Quantity
1 Box

Payment Terms
Western Union, Paypal, Cheque

Supply Ability
10 Boxes Per Day

Delivery Time
2 Days

Main Export Market(s)
Australia, Central America, North America, South America, Eastern Europe, Western Europe, Middle East, Africa, Asia

Main Domestic Market
All India

About LAN Cables STP

Capitalise on the eminent performance of our Customizable STP LAN Cables, engineered for noble reliability across networking and data centers. Available in 23/24 AWG variants, these flame-retardant (IEC 60332-1) cables are RoHS compliant and designed for instant checkout. Experience up to 350 MHz bandwidth and a celebrated 1 Gbps data rate. Minimize interference with shielded twisted pairs and robust aluminum foil/braided copper protection. Each cable is forged from pure copper with high-density PE insulation, boxed or reeled for versatile, indoor applications-enhanced for installers, exporters, and suppliers across India.

Superior Surface Application & Versatile Utility

LAN Cables STP excel in both specific and general use scenarios. Their robust construction makes them ideal for deploying in networking, office wiring, patch cables, data centers, and rack installations. The shielded design ensures minimal electromagnetic interference, making them the preferred choice for structured cabling in technical environments. Their reliability and stability provide a clear advantage for users seeking uninterrupted and secure data transmission, supporting everything from critical industrial setups to everyday office connectivity.

Efficient Logistics: Packing, Dispatch & Global Reach

With Stock Ready availability and strong Packing & Dispatch protocols, our LAN Cables STP are prepared for timely Transportation through major FOB ports in India. Suitable for bulk shipping by box or reel, they cater to international demand as a trusted exporter, importer, supplier, and manufacturer. Sample availability ensures customer satisfaction, while our celebrated export market spans Asia, the Middle East, and beyond-bringing India's networking expertise to the world.

FAQ's of LAN Cables STP:

Q: How do shielded twisted pair (STP) LAN cables reduce electromagnetic interference?

A: STP LAN cables are equipped with aluminum foil and braided copper shielding around the twisted pairs. This design effectively minimizes external electromagnetic and radio-frequency interference, ensuring stable and reliable data transmission in various networking environments.

Q: What are the available variants and customization options for these LAN cables?

A: The cables are offered in 23 AWG and 24 AWG variants, with customizable lengths up to 305 meters. Customers can choose between solid or stranded conductors and specify packaging type-boxed or reel-as per their networking requirements.

Q: Where can these LAN cables be ideally used?

A: These STP LAN cables are celebrated for their versatility and are suitable for data centers, office wiring, patch cables, rack installations, and other indoor networking applications requiring high reliability and stable performance.

Q: What is the process for sample assessment before large orders?

A: Samples of LAN Cables STP are available for prospective buyers. Customers can request specific lengths and configurations to assess the cable performance and compatibility before committing to a bulk order, ensuring satisfaction and suitability for their intended use.

Q: What are the key benefits of capitalising on these STP LAN cables?

A: The eminent benefits include reduced crosstalk, flame-retardant safety, consistent high-speed data transfer (up to 1 Gbps), and compliance with international standards like RoHS and IEC 60332-1. Their robust construction is ideal for both industrial and general usage.
