Armoured Cable

Price 135.0 INR/ Meter

Get a Price/Quote

Armoured Cable Specification

Usage & Applications
Electrical supply for industrial, residential and commercial buildings

Armored Material
Galvanized Steel

Cable Type
Steel Wire Armoured (SWA)

Diameter
Variable according to size

Weight
Variable as per size and length

Insulation
Polyvinyl Chloride (PVC)

Conductor Shape
Round

Install Type
Direct burial, Trays, Ducts

Core Material
Copper/Aluminum

Conductor Type
Stranded

Number of Conductor
2, 3, 3.5, or 4 Core

Dielectiric Strength
3 kV for 1 minute

Features
High tensile strength, Flame retardant, Moisture resistant, Anti-corrosive, Durable construction

Tensile Strength
Highly resistant; exact value depends on construction

Rated Temperature
70C (max)

Core Number
2 to 4 Core

Operating Temperature
-10C to +70C

Impedance
Depends on size and type

Product Type
Armoured Cable

Length
100 meter (standard) or as required

Voltage
Up to 1100V

Insulation Material
PVC

Application
Power distribution, Underground wiring, Industrial installations

Conductor Material
Aluminum or Copper

Jacket Material
PVC

Storage Temperature
-15C to +70C

Shield Material
Steel (Galvanized Steel Wire Armored)

Jacket Color
Black

Dimension (L*W*H)
Customized sizes available

Color
Black

Material
PVC, Copper/Aluminum, Steel

Size
1.5 sqmm to 400 sqmm

RoHS Compliant
Yes

Inner Sheath
Extruded PVC

Outer Sheath
UV resistant Black PVC

Sheath Marking
Size, Type, Voltage, Manufacturer & Year

Earth/Screen Wire
Available on request

Fire Resistance
Flame retardant as per IEC 60332-1

Minimum Bending Radius
12 x Overall Diameter

Packing Type
Wooden drum or coil

Armoured Cable Trade Information

Minimum Order Quantity
100 Meter

Payment Terms
Western Union, Paypal, Cheque

Supply Ability
5 Per Day

Delivery Time
2 Days

Main Export Market(s)
Central America, North America, South America, Eastern Europe, Western Europe, Middle East, Asia, Australia, Africa

Main Domestic Market
All India

About Armoured Cable

We deal in good quality 3 Core Copper Armoured Cable with the most superior standards and performance available

Features:

Less power consumption

High Accuracy

Longer working life

High Stability

Reliable and Powerful

Economical

Engineered for Extreme Reliability

Constructed with high tensile strength galvanized steel armouring and a durable, UV-resistant PVC outer sheath, this cable excels in challenging environments. Moisture resistance and an anti-corrosive build ensure a long service life for both industrial and commercial installations.

Versatility in Application and Size

Available in 2, 3, 3.5, or 4-core configurations with conductor sizes ranging from 1.5 sqmm to 400 sqmm, our armoured cables are customizable for both underground and above-ground power distribution. Options for conductor material (copper or aluminum) and packaging (wooden drums or coils) provide flexibility for diverse project needs.

Certified Safety and Environmental Compliance

This cable meets flame retardant requirements of IEC 60332-1, delivers a dielectric strength of 3 kV for 1 minute, and maintains RoHS compliance. Its fire-resistant construction, proper sheath marking, and durable insulation ensure maximum operational safety and regulatory adherence.

FAQ's of Armoured Cable:

Q: How does the armoured cable achieve fire resistance and flame retardancy?

A: The cable's insulation and sheathing are made of flame-retardant PVC that complies with IEC 60332-1 standards, helping to limit flame propagation and maintain circuit integrity during fire incidents.

Q: What applications are best suited for this armoured cable?

A: This cable is ideal for power distribution in industrial, residential, and commercial buildings, especially for underground wiring, ducts, and direct burial applications due to its robust and moisture-resistant construction.

Q: When should I specify a particular core number or conductor material for my installation?

A: The choice of core number (2 to 4) and conductor material (copper or aluminum) depends on your system's voltage, load requirements, and application environment. Our team can assist in selecting the most suitable configuration for your project.

Q: Where can this armoured cable be installed, and what are its environmental tolerances?

A: Designed for both outdoor and indoor applications, it performs reliably in environments with temperatures from -10C to +70C, and its UV-resistant sheath makes it suitable for exposed installations.

Q: What is the process for ordering customized lengths or sizes?

A: You can request customized lengths (standard is 100 meters) and dimensions to match your specific installation demands. Orders are packaged in wooden drums or coils, as required.

Q: How should I handle and store the cable before installation?

A: Store the cable in a dry location, within the specified temperature range (-15C to +70C). Large reels or coils should be handled carefully to avoid bending below 12 times the overall diameter, preventing damage to internal conductors.

Q: What are the main benefits of using this armoured cable in electrical installations?

A: It offers high tensile strength, superior flame and moisture resistance, durability, compliance with safety standards, and is suitable for a variety of installation environments, ensuring long-term safety and reliability.
